Product Features
True dual zero conversion
60A fast battery charging
Input power factor correction
Pure sine wave inverter
Optional MPPT or PWM solar charger
Generator compatibility
Charging current can be selected through LCD
Compatible with power supply voltage or generator power supply
Parallel operation of multiple units
0755-27198839
| Model | SC-GL-3K | SC-GL-6K | |
| Capacity | 3K/3000W | 6K/5000W | |
| Parallel function | Multiple single machine parallel operation | ||
| INPUT | |||
| Rated voltage | 200/208/220/230/240VAC | ||
| Voltage range | 110~160Vac 3% at 50% load;160~300 VAC 3% at 100% load | ||
| Frequency range | 40Hz~70Hz | ||
| Power factor | ≥0.99@ Nominal voltage (100% load) | ||
| (THDi) | ≤5%@Nominalinput voltage | ||
| OUTPUT | |||
| Output voltage | 220Vac or 230Vac | ||
| Voltage regulation (Battery mode) | 1% | ||
| Frequency range (synchronous range) | 57Hz~63Hz or 47~53Hz | ||
| Frequency range (battery mode) | 60Hz±0.1HZ or 50Hz±0.1Hz | ||
| Load crest | 3:01 | ||
| THD | ≤2%THD（linear load）;≤4% THD(non-linear load) | ||
| transfer time | AC to battery mode | 0 | |
| Inverter to bypass | <4ms（typical） | ||
| ECO to battery mode | 8 ms（typical） | ||
| Waveform (battery mode) | Pure sine wave | ||
| EFFICIENCY | |||
| Communication mode | 90%@fully charged battery | ||
| Ecological model | ≥96%@fully charged battery | ||
| Battery mode | 89% | ||
| BATTERY | |||
| Battery type | 48 VDC(lithium, lead-acid) | ||
| Scope of work | 40VDC-60VDC | ||
| Charging method | 3-Step | ||
| Charger current | 10-60A (maximum), adjustable through LCD | ||
| Typical charging time | Restore to 90% capacity in 1.5 hours | ||
| PHYSICS | |||
| Unit size，DxWxH（mm） | 420X440X88 | ||
| weight（kg） | 13 | 15 | |
| ENVIRONMENT | |||
| Humidity | 20-95% relative humidity @0-40°C（non-condensing） | ||
| Noise | <50dB | <55dB | |
| MANAGE | |||
| Intelligent RS-232,USB | Supports Windows 2000/2003/XP/Vista/2008/7/8/10, Linux, Unix, and MAC | ||
| SNMP protocol | Power management from SNMP manager and web browser | ||
| STANDARD | |||
| EMC/Security | CE (EMC: EN62040-2 C2) is suitable for high-voltage models, FCC (Class A) is suitable for low-voltage models, and the battery pack complies with Uli973 | ||
